TH-X00/TR-X00/E-MU Teak/Denon biodynamic general discussion

Thanks Thotstomp, yes. My marbled ebony cups are quite heavy. The additional size and weight overall with the TR-X00’s subtle clamp makes the headphone a bit floaty on my head.

The quilted maple are lighter but are not as dense as the ebony. They have a slightly different sound signature than the marbled ebony.

I feel the larger ear cup design is beneficial to the audible characteristics of the headphone.

2 Likes

Somebody has seen Z’s VC review. :wink: I actually do not have the Ori Suede. They look massive, but I’m intrigued to get a pair after Z’s review.

1 Like

Good to know! Anything that reduces the bass or it’s impact on these cans I’m not interested in. I’m also quite sensitive to treble.

1 Like

Well, I mean… forum.hifiguides.com. :laughing:

I should mention that the bass is much more like stock with the attenuation rings. The highs are still a slight bit elevated compared to stock and the vocals seem a bit less in-your-face.

1 Like

Edit: For both the dekoni and ZMF pads the driver side portion of the Lawton tune up reduces the slight sibilance mentioned. It does not change the sound but improve it (better separation and less sharpness). I found it to be very easy to install and well worth it. With this mod any pad mentioned is worth it with attenuation rings.

--------------------Original post--------------------

I’ve been doing a lot of pad swapping on my TR-X00 PH over the past few days and I’m finally ready to share my thoughts.

First I want to state that NONE of these pads sound BAD. My Purple Hearts always sounded good with each pad, just different. Some of the changes might be considered unacceptable to some but none of the changes made the headphone sound technically worse in any significant way (Other than what I consider to be a small amount of sibilance only on poorly recorded vocals). Also I am using home made attenuation rings that I made out of the soft vinyl front of a spiral notebook. From what I can tell the hole is slightly smaller than dekoni’s rings and is a little bit further forward. I posted a picture of my attenuation rings in this thread previously (possibly in the Ebony thread). Lastly I would like to mention that I am not particularly treble sensitive, but do listen at somewhat high volumes.

These are the two main songs I used for testing. I focused on the treble and bass the most as these are the areas that changed the most with each pad.

Queen had good forward vocals and could occasionally bring out some sibilance. Also the tambourine was a good test of harsh non vocal related highs. The kick drum had a good kick to it (go figure) for testing bass impact/kick.

(I did not use the Youtube video for testing, I used an mp3 from here)
This song has vocals that will pretty much show any sibilance a headphone has without being artificially or unnaturaly sibilant. It also has some good sparkly highs that can get lost in some bass heavy headphones. The bass line has a good texture to it that feels flatter if the bass is reduced to much.

Accessory House Global:

Comfort:
These pads are sheepskin and a slightly less slow memory foam. They are more comfortable than the stock pads but still sit on the tip and lobe of my ear. The memory foam helps to prevent this from causing sore spots and the sheepskin breathes a bit more so they don’t get as hot as stock pads. The memory foam also helps to keep these in place on my head a bit better than stock pads.

Quality:
These pads are made rather well, but defiantly the worst of the ones I’ve tried. This is only because the built in attenuation ring and fabric piece are not attached at the edges, only the middle, so you can peal the leather back and see the foam. This isn’t a big deal to me and actually makes it a bit easier to put in the mounting rings. Overall good pads, especially for $30.

Sound:
These pads cause absolutely no increase in the highs at all. In fact they might even reduce some peaks ever so slightly, though I’m not entirely sure (if they do it’s a very Very slight decrease). Overall I can’t tell any difference with the mids or the bass. It all seems to be about as close to stock as possible, just with better comfort.

Dekoni Sheepskin:
Only available on Massdrop or you have to contact dekoni directly

Comfort:
Better than stock. The leather is the most shiny but this did not bother me any more or less than any other leather I’ve tried. The ear hole is JUST big enough for my ears, which are slightly large. The memory foam is VERY slow and very soft once it heats up. Very good comfort overall. This is what Fostex should have made the stock pads like comfort wise. Lastly these pads stay in place very well (probably due to the tight ear hole).

Quality:
Very good quality over all. The stitching is good, the leather is very nice, and the lips is a nice flexible vinyl. The only complaint I would have is that one pad is SIGHTLY mis-shaped. It is still perfectly comfortable and not at all an issue. Its the kind of variation one can expect form real leather.

Sound (No attenuation rings):
These are the only pad that I would not entirely recommend. The highs peak a bit (most of any pad). This causes some minor sibilance (also the most of any pad). the bass, particularly the mid-bass is very much reduced, to the point of being damn near neutral. Also the amazing kick of the bass is totally gone. The mids seem to be mostly unchanged (other than the lower-mids/mid-bass). Like I stated at the beginning, these do not sound bad, they just make the most changes in ways that I don’t like and I imagine most other would not either.

Sound (WITH attenuation rings):
Overall much better than without. The bass is back, along with the kick. The highs are slightly reduced, but still boosted compared to stock. The sibilance is less as well and no longer quite as much of a problem in my opinion. With attenuation ring, these are a good option and I would recommend them.

ZMF Ori Lambskin:

Comfort:
These are defiantly the most comfortable. The leather is the least shiny and they are 100% over ear (Like an easy three knuckle). They are also the thickest/deepest of the pads. The only downside to these pads is that they do not stay in place as well as the dekoni pads (still better than stock and a bit better than accessory house). They have probably the fastest memory foam of the three pads.

Quality:
All the stitching is great and the leather is all very uniform in shape. The only issue is the lip that holds the pad on is rather large compared to the other pads so it can get caught in the mounting tabs if you are not careful.

Sound (No attenuation rings):
The treble is again a bit boosted, though not as much as the dekoni without rings. The sibilance is still greater than stock but less so than dekoni without rings. The bass is reduced a bit. It is still better than dekoni without rings and is a good option if the highs are not an issue and you want a more neutral sound. there is still a good amount of bass kick but still less than stock or dekoni WITH rings. The most unique change is that these pads add a bit of sound stage and and make the mids feel a bit less intense.

Sound (With attenuation rings):
Still more treble than stock but less than no rings (probably the least other than accessory house). The sibilance is a touch better/less noticeable but still there (probably the best other than accessory house). the mids are about the same as without rings. They have the same extra sound stage and less intensity. The bass is about stock again. Overall I would recommend this over Ori without rings unless the sightly more neutral bass is really important to you.

So my overall ranking would be:

  1. Accessory House global (These completely replace stock pads. There is no need mention them)
  2. Ori (with attenuation rings)
  3. Dekoni (with attenuation rings)
  4. Ori
  5. Dekoni

Conclusion:
The cheapest pads are the best but least comfortable (still better than stock). The Ori and Dekoni pads are great with attenuation rings (about equal with each other) but the Dekoni pads are not a great choice without attenuation rings, so the Ori are a better without rings. Just get the Accessory House Global pads and if the comfort still isn’t good enough, I imagine the right kind of foam in front of the driver could fix the bit of sibilance the Ori and Dekoni pads introduce.

3 Likes

Thank you for the detailed review/analysis!

I’m about to embark on a full Lawton mod (chambers ordered yesterday). I think based on what I’ve read, including your review, I’m going to try the ZMF Ori pads. Sibilance shouldn’t be an issue, as the mod addresses that from my understanding. And those Ori pads look nearly as lush as the Audeze pad which I love.

Thanks again.

1 Like

What part of the mod is supposed to help with sibilance?

The “Tuneup”, I believe.

It corrects resonances from the drivers which smooths out the frequency response (which can reduce sibilance). It makes it less of a V-shaped response and more neutral. It’s more apparent on the higher energy driver (1.5 Tesla) that the TH900mk2/TH909 series headphones use.

The TH610/DropTR-X00/Emu-Teak use a lower energy driver (just over 1 Tesla). Denon use both drivers depending on which model.

2 Likes

I can concur. This is also why I can use the ZMF pad without attenuation rings and I get a better overall tonality than stock with the Lawton driver mod and cups. It all adds up to a superior performing headphone.

2 Likes

So just the vinyl strips reduce resonance or both the strips and the foam in the cups?

" Our Original Upgrade. Improved!

Our most popular and famous upgrade for your Fostex/Denon is now in its third generation. The company that started the whole headphone tuning craze back in ‘07 has completely re-invented our revolutionary process from the ground up.

The Lawton Tune-Up: Our #1 Mod For All Fostex & Denon (E-MU, TOO!)

Overall, you can think of what we do at Lawton Audio as being akin to taking a superb commercial speaker driver array from a mass-market floor-stander, totally re-wiring and re-housing it in a superior cabinet. The net benefits for your headphones are just as dramatic and easily appreciable by any listener. We don’t upgrade these phones because we want to re-shape them to our tastes. We love that magical Fostex sound; that’s why we’re dedicated to unlocking their full potential.

The cornerstone of our process is something we call our Tune-Up procedure, a simple common-sense approach to resonance control. Our technique has been copied and applied to many other headphones by experimenters using our original ideas as a foundation. Clearly it has proven its worth. We love it!

Effective. Inexpensive. “The Only Headphone Mod That Works.”

We have no more potent upgrade than our Tune-Up, and it is one of our most affordable as well. $99 installed on your Fostex, or $45 as a D.I.Y. Kit. One reviewer calls it “the only headphone mod that works”. The Tune-Up gives you the biggest bang-for-your-buck improvement from our entire menu of services. Combine the Tune-Up with a pair of our custom leather Angle Pads and you have our Level 1 Upgrade, our basic mod package for all Fostex headphones ($189 installed, $135 D.I.Y. Kit).

Tune-Up Your Fostex for Maximum Performance!

Our Tune-Up process improves your headphone’s response by eliminating multiple sources of distortion that all originate from a common enemy: vibration. We recognized that a headphone’s housing functions not unlike a speaker cabinet that resonates in time with the music. Unchecked, this can introduce unpleasant distortions. Our Tune-Up procedure goes right to the heart of the problem.

Tune Out Distortion, Rev Up Your Fostex!

The drivers in your Fostex are extremely potent and powerful examples of dynamic style transducers. Many listeners prefer dynamic headphones precisely because they are capable of creating lots of energy and brute force that helps make the music sound lively and thumpin’. The Fostex can generate a lot of oomph in a hurry and can really flow and explode with musical crests and crescendos.

Due to their lively nature, these drivers transfer large amounts of their energy to the frame and cups where it gets dissipated and muddies up the music. Even worse, it weakens impact by robbing your music of this same energy, wasting it throughout the chassis instead of concentrating it within the thundering drums or heavy bass lines like it should.

Our revolutionary Tuning for Fostex addresses these fundamental issues, removing layers of grunge-y mud caused by these excess vibrations in your headphones. Bass gets harder, faster, cleaner and much more tuneful and articulate as well. The sound becomes more focused, clean, and accurate; now the music flows and pumps with greater ease, distortion free.

Improve Clarity & Resolution Of Fine Detail

The benefits of our Tune-Up don’t stop in the bass department; customers report mids and highs are cleaner, clearer, and better integrated into the whole. Sound overall is more balanced, accurate, and small nuances and details are better conveyed. Listening fatigue is reduced, allowing you to enjoy your music longer and in a more relaxed fashion.

A New Level of Performance & Musicality

As reported over and again by reviewers, D.I.Y.-ers, and happy customers alike, our Tune-Up delivers a stunning enhancement for your Fostex and more pleasure from your music. So now you can rock on, comfortably."

1 Like

Ok. So both. My last question is how hard is it to remove the vinyl strips if I for some reason don’t like it?

It would be easy, but you won’t want to.

2 Likes

You would be better off getting a spare pair of cups or selling them at that point imo lol

1 Like

If I decided to try the foam in the cups I wouldn’t use the adhesive for testing. I would probably use some bluetack.

Hello,
I use the Lawton Mod stage 1 with the Angelpads.
And they are the best what you can do.
The Pads are the best after the original i find.I have tried the Dekoni hybrid elite and they are so bad forit.A chinese pad they was better as the Dekoni.
What i would try is to change the Cups and go away from the Mahagony Cups.
But the Cups from Lawton are a little bit expensiv for me but i will do it.
But not sure what way from the cups i will go.
Actually i find the Mahagony the highs are to much,the bass is not so beautiful.
I can recomand the Lawton mod stage 1 for all.Is a good and simply thing.
I hope Massdrop think about to bring the Fostex tr x00 to the return of the market.Is one of the best phones i find.

2 Likes

Hey Deleeh. Thanks for your insights. I agree the Lawton pads are a fantastic alternative. They are the second favorite pad I’ve tried. I’m just personally a fan of the larger ZMF pad because it’s a better fit on my ears and I prefer the slightly added soundstage, but you can’t go wrong with anything Lawton makes.

If you’re thinking about going with some Lawton cups, I highly recommend them not only for their aesthetic but what they can do for the sound of the headphone. If you want my personal recommendation, I’d begin with a level 5/more dense wood if you’re looking for the most flat response.

Good luck and let us all know how you make out!

FYI… I believe Mark has ended up using different sound absorption materials in his mods and they have changed over time as he more and more experience. They will not be the same as using basic foam.

2 Likes

Agreed on the Drop comment (I haven’t completed the Lawton mod yet, but I’m sure I’ll agree with your observations.).

As a matter of fact, I purchased the Lawton Chambers (cups) prior to purchasing a Fostex headphone! The mod was pending on whether or not Lawton would have the Chambers I wanted (he did). Now after having just ordered the Chambers, Drop is “Out of Stock” on all fostex! :laughing:

My Chambers won’t be ready for another 2-4 weeks, and this headphone/mod was going to be my birthday present (mid February) so I’ll just have to wait and see if Drop brings them back or if I have to get a TH900mk2 (which has the better driver).
